STANDARDS: ASTM C39 | AASHTO T22 | BS 1610 | GOST 10180-2012
DIAL GAUGES MODELS
Gauges Ø 250 mm with specific
resistance scales for cubes 150 mm
and cylinders Ø 150 – 160 mm
Gauges divisions: 2000 kN div. 5 kN
600 kN div. 2 kN
MAIN FEATURES FOR ALL MODELS
Max. vertical daylight: 282 mm
Horizontal daylight between columns: 270 mm
Compression platens Ø 287 mm
High stiffness and heavy weight 4 columns frame
(german-style).
Calibration accuracy: Class 1
Max. ram travel 55 mm approx.
Power supply: 230V 1ph 50Hz 750W
Dimensions: 690x400x1320 mm approx.
Weight: 670…720 kg
