CONFINED FLOWABILITY DETERMINATION J-RING APPARATUS

Category:

STANDARD: EN 12350-12
To determine the flowability, i.e. the flow time and the capability of
the self compacting concrete to pass through obstacles.
C174 N
J-RING APPARATUS, galvanized steel made, having rectangular
section 30×15 mm and median diameter of 300 mm.
The median circumference of the ring is drilled, and n. 16 cylindrical
bars Ø 18×140 mm are fixed into the holes.
The bars have a close distance of 41 mm between them, to simulate
a condition of higher density of the reinforced bars.
C174-01N
J-RING APPARATUS, similar to C174N, but having n° 12 cylindrical
bars and 59 mm distance between them, to simulate a condition of
standard density of the reinforced bars.
C170
SLUMP CONE, galvanized steel, conforming to EN 12350-2 Spec.
C170-01
PLATE, galvanized steel made, dimensions 900×900 mm, with
engraved two circles having 210 and 500 mm diameter and central
X cross.
C183
VEBÉ CONSISTOMETER
STANDARD: EN 12350-3
The Vebé consistometer method is based on the same principle of
the simple slump cone test method, for the determination of the
workability of concrete, but it has the advantage of a mechanized
action. After removing the slump cone, the concrete
undergoes a vibration to determine its slump.
Supplied complete.
Power supply: 230V 1ph 50Hz 250W
Dimensions: 260x380x700 mm
Weight: 90 kg approx.

C184N
VIBRATING TABLE (Vebé consistometer)
STANDARD: ASTM C1170-14
For determining the consistency and density of roller-compacted
concrete. Similar to mod. C183, but conforming to ASTM C1170-14
Spec. with sliding weight of 50 lbs
* Power Supply: 230V 1F 50Hz 180W
Dimensions: 280x400x900 mm
Weight: 110 kg approx.
*Note: The vibrating table is available also at:
230V 60Hz and 110V 60Hz

ACCESSORY for the C184N table
C184-10N SLIDING WEIGHT 20 LBS (that
replaces the standard 50 lbs
one) + base to fix a cylinder
mould Ø 6”x12” (optional
mod. C258-03) to conform
the Vibrating Table to the
ASTM C1176-14 Specifications.
